24″ HD DLED TV (LE-24P28-3663)

24″ HD DLED TV

Model:LE-24P28-3663
Solution:MSD3663S/MSD3663
Market:Asia Pacific/Europe/South America
Resolution:1366*768
Screen Size:24 Inches
Aspect Ratio:16:9

Description

The impressive HD resolution and the DLED technology

for a visual feast

This HD DLED TV with 1366.768 resolution, providing an immersive home theater experience through

distortionless pictures and in strong contrast colors.

The DLED technology offers you a much improved contrast pictures.

3D comb filter built-in TV

3D comb filter separates the luminance signal from the chromatic signal, and three horizontal scan lines work at a time. The effect it brings is to eliminate or reduce video noise, and present the viewer a much clearer video.

NICAM Stereo Sound

The NICAM stereo sound can broadcast a high-quality stereo, offering you a stunning sound effect.

Compact size for multiple scenes

The size of 24 inches is suitable for your bedroom/kitchens/gyms… and the streamlined design creates vitality to your home.

Specifications

Panel Maker

INNOLUX

Display type

DLED

Aspect Ratio

16:9

Resolution

1366*768

Brightness

180cd/㎡

Contrast

3000:1

Viewing Angle

178°* 178°

Maximum Colors

16.7M

Response Time

8.5ms

Solution(AP+EU)

MSD3663S

Solution(LA)

MSD3663

OS

NO

Memory

128B RAM Inside

Comb Filter

3D

Video System(AP+EU)

PAL SECAM

Video System(LA)

ATV:PAL,NTSC

DTV:ISDB

Progressive Scan

YES

HD Ready

YES

YPbPr Resolution

480i/p,576i/p, 720i/p,1080i/p

PC Resolution

UP to  1366*768 @ 60Hz

Color Temperature Adjustment

YES

Audio System(AP+EU)

B/G,D/K,I

Audio System(LA)

M/N

Stereo Sound(AP+EU)

NICAM

Stereo Sound(LA)

YES

Maximum Audio Output

2×3W

Equalizers

YES(4 Modes)

Effects

YES

AV IN(LA)

1

CI(EU)

1

CVB(AP)

1

YPBPR(AP+LA)

1

EARPHONE

1

HDMI

1

L/R AUDIO IN(AP)

1

MINI AV(EU)

1

MINI YPBPR(EU)

1

PC Audio In

1

S2(EU)

1

SCART(EU)

1

TV(AP+EU)

1

USB

1

VGA(AP+EU)

1

VGA(D-Sub 15pin)(LA)

1

COAXIAL

1

Power Requirement

100-240 @ 50/60Hz

Power consumption(Operation)

≦36W

Power consumption(Standby)

≦0.5W

ETL

NO

FCC

NO

UL

NO

Remote controller(English)

YES

Wall-mount Bracket

OPTIONAL

Remote Batteries

YES

User Manual

YES

Stand

YES

Packing

Unit(mm)

551*328.4*70.3

1Pc/1Carton

(mm)

623*123*395

Net(Kg)

2.42

1Carton(Kg)

3.2

40HQ

2200PCS
