24″ FHD/HD DLED TV (LE-24Z1-3663 )

24″ FHD/HD DLED TV

Model: LE-24Z1-3663

Solution:MSD3663S/MSD3663
Market:Asia Pacific/Europe/South America
Resolution:1920*1080/1366*768
Screen Size:24 Inches
Aspect Ratio:16:9

Description

Specifications
Packing

Specifications

Panel

Panel Maker

INNOLUX

Display type

DLED

Aspect ratio

16:9

Resolution (South America)

1366*768

Resolution (AP+EU)

1920*1080

Brightness

180cd/㎡

Contrast

3000:1

Viewing Angle

178°* 178°

Maximum Colors

16.7M

Response Time

8.5ms

SOLUTION

Solution(EU)

MSD3663S

Solution(AP+LA)

MSD3663

OS

NO

Memory

128B RAM Inside

Comb Filter

3D

Video

Video System (South America)

ATV:PAL,NTSC/DTV:ISDB

Video System (AP+EU)

PAL SECAM

Progressive Scan

YES

HD Ready

YES

YPbPr Resolution

480i/p,576i/p,720i/p,1080i/p

PC Resolution(South America)

UP to 1366 x 768 @ 60Hz

PC Resolution(AP+EU)

UP to 1920×1080 @60Hz

Color Temperature Adjustment

YES

AUDIO

Audio System(South America)

M/N

Audio System(AP+EU)

B/G,D/K,I

Stereo Sound

NICAM(AP+EU)

YES (LA)

Maximum Audio Output

2×3W

Equalizers

YES(4 Modes)

Effects

YES

Connectivity

EARPHONE

1

COAXIAL(AP+LA)

1

USB

1

HDMI

1

PC AUDIO IN

1

VGA(D-Sub 15pin)(LA)

1

VGA(AP+EU)

1

TV(AP+EU)

1

L/R AUDIO IN (AP)

1

YPBPR (LA)

1

CVB&YPBPR (AP)

1

SCART(EU)

1

MINI AV(EU)

1

MINI YPBPR(EU)

1

CI(EU)

1

Power

Power Requirement

100-240 @50/60Hz

Power consumption(Operation)

≦36W

Power consumption(Standby)

≦0.5W

Certifications

ETL

/

FCC

/

UL

/

Accessory

Remote Controller

YES

Wall-mount Bracket

OPTIONAL

Remote Batteries

YES

User Manual

YES

Stand

YES

Packing

Dimension

Unit(mm)

551*328.4*70.3

1Pc/1Carton

(mm)

623*123*395

WEIGHT

Net(Kg)

2.42

1Carton(Kg)

3.2

LOADING

40HQ

2200PCS
