32″ HD DLED TV (LE-32Z1-5522)

32″ HD DLED TV

Model:LE-32Z1-5522
Solution:MSD5522/MSTAR V5522
Market:South America/Europe
Resolution:1366*768
Screen Size:32 Inches
Aspect Ratio:16:9

Description

Specifications

Panel Maker

CSOT/AUO/INNOLUX/BOE/IPS

Display type

DLED

Aspect ratio

16:9

Resolution

1366*768

Brightness

200cd/㎡

Contrast

3000:1

Viewing Angle

178°* 178°

Maximum Colors

16.7M

Response Time

8.5ms

Solution(EU)

MSTAR V5522 Without AC-3

Solution(LA)

MSD5522

OS

Android 7.0

Memory(EU)

4GB/8GB Flash
1GB RAM Inside

Memory(LA)

DDR 1GB/1.25GB Inside
4GB/8GB Flash

CPU/GPU

A53*4, Mali450*2

Comb Filter

3D

Video System(LA)

ATV:PAL,NTSC/DTV:ISDB

Video System(EU)

PAL SECAM

Video System

DTV:ISDB

Progressive Scan

YES

HD Ready

YES

YPbPr Resolution

480i/p,576i/p, 720i/p,1080i/p

PC Resolution(LA)

UP to 1366×768 @ 60Hz

PC Resolution(EU)

UP to 1920×1080 @60Hz

Color Temperature Adjustment

YES

Audio System(LA)

M/N

Audio System(EU)

B/G,D/K,I

Stereo Sound(LA)

YES

Stereo Sound(EU)

NICAM

Maximum Audio Output(LA)

2×8W

Maximum Audio Output(EU)

2×10W

Equalizers

YES(4 Modes)

Effects

YES

AV IN

1

YUV(EU)

1

EARPHONE

1

USB(EU)

2

USB(LA)

1

VGA(D-Sub 15pin)

1

PC AUDIO IN

1

COAXIAL

1

HDMI(EU)

2

HDMI(LA)

3

Power Requirement

100-240 @50/60Hz

Power consumption(Operation)

≦56W

Power consumption(Standby)

≦0.5W

ETL

NO

FCC

NO

UL

NO

Remote controller(English)

YES

Wall-mount Bracket

OPTIONAL

Remote Batteries

YES

User Manual

YES

Stand

YES

Packing

Unit(mm)

729*429*77.4

1Pc/1Carton

(mm)

785*130*490

Net(Kg)

4.2

1Carton(Kg)

5.1

40HQ

1340PCS
