24” HD DLED TV (LE-24Z1-530)

55” UHD DLED TV

Model:LE-24Z1-530
Solution:Hi3751
Market:Asia Pacific
Resolution:3840*2160
Screen Size:55 Inches
Aspect Ratio:16:9

Description

Specifications
Packing

Specifications

Panel

Panel Maker

INNOLUX

Display type

DLED

Aspect ratio

16:9

Resolution

3840*2160

Brightness

180cd/㎡

Contrast

3000:1

Viewing Angle

178°* 178°

Maximum Colors

16.7M

Response Time

8.5ms

SOLUTION

Solution

Hi3751 With AC-3

OS

Android 5.1

Memory

4GB/8GB Flash
768MB RAM Inside

CPU/GPU

A53*2, Mali450*4

Comb Filter

3D

Video

Video System

PAL SECAM

Progressive Scan

YES

HD Ready

YES

YPbPr Resolution

480i/p,576i/p,720i/p,1080i/p

PC Resolution

UP to 1920×1080 @60Hz

Color Temperature Adjustment

YES

AUDIO

Audio System

B/G,D/K,I

Stereo Sound

NICAM

Maximum Audio Output

2×8W

Equalizers

YES(4 Modes)

Effects

YES

Connectivity

PC Audio In

1

TV

1

COAX

1

HDMI

2

USB(3.0)

1

USB(2.0)

1

RJ45

1

AV IN

1

VGA(D-Sub 15pin)

1

YUV

1

(Mini)Line out

1

TF Card

1

Power

Power Requirement

100-240 @50/60Hz

Power consumption(Operation)

≦135W

Power consumption(Standby)

≦0.5W

Certifications

ETL

/

FCC

/

UL

/

Accessory

Remote controller(English)

YES

Wall-mount Bracket

OPTIONAL

Remote Batteries

YES

User Manual

YES

Packing

Dimension

Unit(mm)

551*328.4*70.3

1Pc/1Carton

(mm)

623*123*395

WEIGHT

Net(Kg)

2.42

1Carton(Kg)

3.2

LOADING

40HQ

2200PCS
