32″ C Series Monitor (LM-32C2)

32″ C Series Monitor – LM-32C2

Model:LM-32C2
Resolution:2560*1440
Contrast: 3500 : 1
Response Time:OD 3ms MPRT 1ms
Max. display frequency:2560*1440 165Hz
Screen Size:
31.5 Inches
Aspect Ratio:16:9

描述





C series Gaming Monitors

The new Express LUCK Curved Series gaming monitors provide the most immersive experience to gamers. Available from 27” to 34”. Rapid refresh rate up to FHD @240Hz/ QHD @165 Hz enables smooth graphics and the most responsive gaming experience, giving you a stunning visual experience and the best competitive advantage.





Curve design

The curved monitor R1500 display provides gamers with the most immersive experience, bringing the screen’s sides more within your field of view.





Picture in/by Picture

Picture-in-Picture (PiP) and Picture-by-Picture (PbP) modes let you simultaneously view content from two inputs. It separates into two screens on the left and right, maximizing the space of your monitor.





Ergonomic Stand

Swivel and adjust your monitor for convenience, elevating your performance. Also, there are three types of stands that you can choose.





USB Type-C™ High-Performance Connection

The monitor has the latest USB Type-C connection that supports 65W charging. You can enjoy the gaming experience by charging all by one single cable, synchronizing the monitor with your gaming device and charging it at the same time.

Specifications

Curved / flat

Curved 1500R

OC

CSOT SG3151G02-3

Surface Treatment

SAG 25%, 3H

Panel type (Display Mode)

VA panel

Brightness(Typical)

300 cd/m2 (Typ.)

Contrast(Typical)

3500 : 1

Pixel Pitch(mm)

0.2724(H) x 0.2724(V)

Resolution (H x V)

2560*1440

Aspect Ratio

16:9

Response Time(Typical)

OD 3ms MPRT 1ms

View Angles LR,UD(CR=10)

178°(H) /178°(V)

Display Colors

16.7M

NTSC(Area)

72%

MPRT 1ms

MPRT 1ms

Anti-flicker

Yes

G-Sync

NA

Free Sync

Yes

Anti-Bluelight

Yes

HDR/DCR

HDR 10

Over Drive

Yes

Anti-glare

Yes

Daisy Chain

NA

USB C DisplayPort Alternate Mode

NA

Horizontal Freq.

13.1 to 129.6KHz

Vertical Freq.

48 to 240HZ

Max. display frequency
(Resolution H*V/Fv)

2560*1440 165Hz

HDMI2.1

x2

DP1.4

x2

Earphone

Yes

Speaker(Typical, Amplifier output)

optional 4Ω 3W*2

Front Control

NA

On Screen Display

12 Language: English, French, German, Chinese, Italian, Spanish, Portuguese, Turkish, Polish, Dutch, Korean, Japanese

Color

6500、7500、9300、User

Preset Mode

GAME、MOVIE、PHOTO、STADNARD

Consumption(Typical)

On: <48 W
Standby<=0.5W, Off<=0.5W

AC Power Range

100-240V~, 50/60Hz

Power Mode

Adapter DC 12V 4A (PSE) 48W

Tilt

-5°~20°(+/-2°)

Kensington Lock

Yes

VESA Mounting

100×100 (screw hole: 4 holes with M4 x 8 mm)

Power Adaptor

Plug-in adaptorx1

DP Cord(1.5m)

x1

Stands

Assembling stand and base with one M5*10mm screw, the stand and monitor should be easy install , no need screw

User Manual

x1

Packing

With Stand(W*D*H)

714.67*233.88*500.14mm

Without Stand(W*D*H)

718.11*89.74*421.31mm

With Package(W*D*H)

788*185*490mm

Net Weight

5.6KG

Gross Weight

7.6KG

Loading alibilty
W/O Pallet

20′ GP/40GP/ 40′ HQ
400/840/960

Loading alibilty

20′ GP/40GP/ 40′ HQ
288/672/784

Pallet

20′ GP/40GP/ 40′ HQ
6/14/14
